How to use the stopwatch

Standard measurement Ex. 5,000 meters running

8B92_Stopwatch Ex-1 + Stopwatch Ex-1

Start

Stop

Reset

Start the measurement

Goal

Reset the stopwatch to 0 minute 0 second.

Example of measurement:
20 minutes 41 seconds

Button C

Button C

Button D

8B92_Stopwatch Ex-1 V + Stopwatch Ex-1 V

Start

Stop

Reset

Start the measurement

Goal

Reset the stopwatch to 0 minute 0 second.

Example of measurement:
20 minutes 41 seconds

Button C

Button C

Button D

Accumulated elapsed time measurement Ex. Measuring the time for a soccer match

8B92_Stopwatch Ex-2 + Stopwatch Ex-2

Start

Stop

Start

Stop

Reset

Start match.

Stop match.

Start again.

The match ends.

Reset the stopwatch to 0 minute 0 second.

Button C

Button C

Button C

Button C

Button D

Restart and stop of the stopwatch can be repeated.

8B92_Stopwatch Ex-2 V + Stopwatch Ex-2 V

Start

Stop

Start

Stop

Reset

Start match.

Stop match.

Start again.

The match ends.

Reset the stopwatch to 0 minute 0 second.

Button C

Button C

Button C

Button C

Button D

Restart and stop of the stopwatch can be repeated.

Split time (intermediate elapsed time) measurement Ex. 5,000 meters running

“Split time” is the time that has elapsed from the start of an activity to any given stage.

8B92_Stopwatch Ex-3-2 V + Stopwatch Ex-3-2 V

Example of the intermediate elapsed time

Start

P point

Goal

8B92_Stopwatch Ex-3 + Stopwatch Ex-3

Start

Split

Stop

Stop

Reset

Start

The runner passed the P point.

The intermediate elapsed time is displayed.

Goal

(Display of goal time)

Reset the stopwatch to 0 minute 0 second.

Example of the intermediate elapsed time

Start

P point

Goal

Button C

Button D

Button C

Button D

Button D

8B92_Stopwatch Ex-3 V + Stopwatch Ex-3 V

Start

Split

Stop

Stop

Reset

Start

The runner passed the P point.

The intermediate elapsed time is displayed.

Goal

(Display of goal time)

Reset the stopwatch to 0 minute 0 second.

Button C

Button D

Button C

Button D

Button D

Measurement of two competitors

Stopwatch Ex-4 V + Stopwatch Ex-4 V

Ex. Measurement of two competitors

Start

First runner finishes.

Second runner finishes.

8B92_Stopwatch Ex-4 + Stopwatch Ex-4

Start

(Split)

(Stop)

(Split release)

Reset

Start

First runner finishes.

Displays finishing time of first runner

Second runner finishes.

(Still displaying finishing time of first runner)

Check time of second runner.

Displays finishing time of second runner

Reset the stopwatch to 0 minute 0 second.

Ex. Measurement of two competitors

Start

First runner finishes.

Second runner finishes.

Button C

Button D

Button C

Button D

Button D

8B92_Stopwatch Ex-4 V + Stopwatch Ex-4 V

Start

(Split)

(Stop)

(Split release)

Reset

Start

First runner finishes.

Displays finishing time of first runner

Second runner finishes.

(Still displaying finishing time of first runner)

Check time of second runner.

Displays finishing time of second runner

Reset the stopwatch to 0 minute 0 second.

Button C

Button D

Button C

Button D

Button D
