> TROUBLESHOOTING > How to conduct manual reception (Receive a radio signal manually)

How to conduct manual reception (Receive a radio signal manually)

  1. Place the watch.

  2. Place the watch where it can easily receive a radio signal.

    To improve radio signal reception

    Environments in which it is difficult to receive a radio signal

    The watch cannot receive a radio signal outside the radio signal reception range. Radio signal reception range indication

    7B72_How to conduct manual reception-1 + How to conduct manual reception-1

    The antenna is embedded at the 9 o’clock position of the watch. Turning the antenna toward the outside of a window helps improve radio signal reception.

  3. Continue to press and hold the button for 3 seconds, and then release it when the seconds hand moves to the 0-second position.

  4. Reception starts after the seconds hand moves and stops at the 0-second position.

    When the time zone is set for a region other than the radio signal reception range, the seconds hand does not move to the 0-second position. (A radio signal cannot be received manually.) Check the selected time zone.
    How to select the time zone (How to display the local time around the world)

    7B75_How to conduct manual reception-2 + How to conduct manual reception-2

    Press and hold for
    3 seconds

  5. Place the watch and wait for a few minutes (max. 12 minutes).

  6. When the seconds hand moves at the one-second interval, the reception is finished.

    It takes time to receive a radio signal (max. 12 minutes).

    The required time varies depending on the receiving state of a radio signal.

<Display until the reception is finished>

The seconds hand indicates the reception level. (Updated every minute)

Reception level

High : H

Low : L

Display

7B75_Reception_level_H
7B75_Reception_level_L

Receiving state of a radio signal

Easy to receive

Difficult to receive

In conjunction with the seconds hand movement, the minute hand advances by one minute.

<If the reception has failed>

The seconds hand indicates the reception result “N.”

Reception result : N

7B75_Reception_result_N3

After 5 seconds, the watch switches to the time display mode.

If reception has failed: The seconds hand points to N

  1. When the seconds hand starts to move at one-second intervals, check that the reception is successful.

  2. When the reception is finished, check that the reception is successful.

    How to display the reception results

    During movement of the date, neither the button nor the crown can be operated.
